Intelligent Tile Adhesive Making Machine 1000m2 Automatic Dry Mortar Mixer Plant

Brand Name : MG

Model Number : MG-3.7

Certification : CE, ISO, SGS

Place of Origin : China

MOQ : 1 set

Price : negotiable

Payment Terms : T/T, L/C, Western Union, MoneyGram

Supply Ability : 26 sets per month

Delivery Time : 20-25 working days

Packaging Details : Wooden box packing and bubble wrap packing

Name : Tile adhesive making machine

Advantage : Full automatic and intelligent

Raw material : Cement, Sand and additives

Installation service : We send engineer to oversea for guiding installation

Worker required : 3-4 workers

Workshop required : 500-1000m2

Warranty : 12 months

Dimension(l*w*h) : 10000*10000*10000 mm

Application : Dry Mortar Mixing,tile adhesive making machine

Contact Now

Intelligent Tile Adhesive Making Machine Automatic Dry Mortar Mixer Machine

Production Description of Automatic Robot Packaging System and Palletizing Automatic Dry Mortar Mixer Machine:

Automatic Dry Mortar Plant developed by our company is mainly composed of storage unit, conveying unit, batching metering unit, mixing unit, dust collect unit, aerodynamic unit, packaging unit and automatic control unit. The production line can be equipped with advanced distribution units such as additives distribution system, light aggregate pneumatic conveying system and finished product conveying pallet system on the basis of traditional classic configuration, greatly improving the overall efficiency of the production line and realizing green friendly production.

Technical parameters of Automatic Robot Packaging System and Palletizing Machine
Automatic Dry Mortar Mixer Machine:

No. Name Model
1 Raw Material Storage System Detachable Silo
2 Conveying System I Screw Conveyor
II Indoor Bucket Elevator
III Outdoor Bucket Elevator
3 Small additives &weighting system
4 Batching & Weighing System Batching & Weighing Hopper
5 Mixing System I Double Shaft Paddle Mixer
II Premix Hopper
III End Product Hopper
6 Packing System Automatic Robot Valve Port Packing machine
7 Control System PLC Control Cabinet
8 Dedust Part Pulse Dedust Filter
9 High Pressure Air Supply Air Compressor
10 Steel Structure 2-Layer Steel Platform
11 Bag Belt Conveyor(Optional) Roller type belt conveyor
12 Cleaning and climbing conveyor Dust Cleaning and climbing roller conveyor
13 Production date printer Production date printer
14 Palletizing system Palletizing machine
15 wrapping system wrapping machine

Features of MG automatic Automatic Dry Mortar Mixer Machine:

A. It features magnificent appearance, good quality, high productivity and accurate mortar proportioning.

B. The dry mortar production line uses a centralized control system, making the equipment easy to operate.

C. According to the layout type, it can be classified into tower type, self tower type and series type. Its up to the customers workshop area. The needed area is 500~5000m2.

D. We can provide one-stop service from design to installation according to our customers' specific requirement.

Customer Working site of MG Automatic Dry Mortar Mixer Machine:

Intelligent Tile Adhesive Making Machine 1000m2 Automatic Dry Mortar Mixer Plant

Technical parameter of MG full Automatic Dry Mortar Mixer Machine:

Model MG3.7 plant MG3.8 plant
Capacity 10-15T/H 20-30T/H
Total power 85.9kw 125kw
Workshop Area 400-500m² 600-800m²
Worker Required 2-3person 3-4person

Application of MG Automatic Dry Mortar Mixer Machine:
Dry mix mortars are used in many different applications in the construction of a building. Some of these applications are universal and some others are specific to certain regions or countries. The key dry mix applications are:

1.wall putty

2.tile or floor adhesive mortar

3.masonry mortar

4.self-leveling mortar

5.tile or floor grout mortar

6.base-mortar

7.anti-crack mortar

8.water-proof mortar, etc.

Main configuration of MG full automatic Automatic Dry Mortar Mixer Machine:
1, Materail storage silo
2, Screw conveyor
3, Weighing hopper
4, Bucket elevator
5, Premix hopper
6, Double shaft paddle mixer
7, Finis product hopper
8, Automatic packing machine
9, Dust collector
10, Air compressor
11, PLC control system
12, Bag belt conveyor
13, Pallet wrapping machine

Factory and workshop of Zhengzhou MG:

Intelligent Tile Adhesive Making Machine 1000m2 Automatic Dry Mortar Mixer Plant

Manufacturing equpment of Zhengzhou MG:

Intelligent Tile Adhesive Making Machine 1000m2 Automatic Dry Mortar Mixer Plant

Customer visit our factory for the full automatic tile adhesive making machine:

Intelligent Tile Adhesive Making Machine 1000m2 Automatic Dry Mortar Mixer Plant

MG full automatic tile adhesive making machine loading to foreign customers:

Intelligent Tile Adhesive Making Machine 1000m2 Automatic Dry Mortar Mixer Plant

Successful projects of Zhengzhou MG:
Intelligent Tile Adhesive Making Machine 1000m2 Automatic Dry Mortar Mixer Plant

FAQ:

1, How about the investment of this project?

A: Our engineer can design the dry mortar plant as your requirement and your budget, different dry mortar plant investment are difference.

Low capacity low cost, we will provide you cost effective solutions as your requirement.

2, What's the difference between full automatic dry mortar plant and Semi-automatic dry mortar plant?

A: (1) Semi-automatic dry mortar plant is cheaper than full automatic dry mortar plant.

(2) Semi-automatic dry mortar plant do not need to equip silos while full automatic dry mortar equip material silos.

(3) Semi-automatic dry mortar is manual feeding and automatic weighing and packaging, Full automatic dry mortar plant is automatic feeding and automatic weighing and packaging.

3, How many people required to operate this dry mortar plant?

A: Usually 2-4 workers are enogh to operate this dry mortar plant.

4, What equipment and service you can provide?

A: We can provide you turnkey solution of dry mortar plant from working site planning to dry mortar machines, transportation, installation and training, formula of dry mortars, after-sales services, life time technical support etc.

5, What is the area required for this dry mortar plant?

A: According to the capacity of the dry mortar plant, the area required 300-100 m2.

6, What is the total power consumption (KW) of this dry mortar plant?

A: It is 20-80W based on the capacity of the dry mortar plant.

7, What is the capacity of your dry mortar plant?

A: We have dry mortar plant with capacity 3-30T/H as your requirement, and also we can customize the dry mortar plant as your capacity requirement.

8, How long is the guarantee period?

A: 12 months, within this period, we provide you spare parts and services for free.

9, Can you install the dry mortar plant in my country?

A: Yes, we will send engineers to your country for guiding installation and training your workers to operate the machine.

If you want to know more of our dry mortar plant, please send us inquiry or contact us directly.

Warmly Welcome to contact us for more information !
